Application
◆ Can be used to repair XLPE cable terminations and joints or shielding for other devices up to 110kV.
◆ Retains its conductivity when stretched.
◆ Semi-conducting (low resistivity).
◆ Suitable for irregular shapes cable with good elongation.
◆ Withstand high temperatures (130°C/266°F) short-term overload.
◆ Compatible with all solid dielectric cable insulations and conductors.
◆ Resistance to ozone, solvents, UV, xenon exposure and moisture.
◆ Suitable for indoor or outdoor applications.
◆ Operation and installation easily.
◆ Increases its conductance and will not harm it in any way.
Product Features
l Semi-conducting;
l Retains its conductivity when stretched;
l Withstand 130°C/266°F short-term overload;
l Resistance to ozone, UV, and xenon exposure;
Technical Properties
No. | Test Item | Result | Test Method |
1 | Color | Black | |
2 | Thickness | 0.76mm | ASTM D4325 |
3 | Tensile Strength | ＞1.73MPa | ASTM D4325 |
4 | Elongation at Break | ＞935% | ASTM D4325 |
5 | Water absorption | 0.19% | ASTM D570-98 |
6 | Volume resistivity | ＜7x106 Ώ.cm | ASTM-D4325 |
7 | Heat ageing(130℃ 168H) | Pass | ASTM D4325 |
8 | UV ageing | Pass | ASTM D4325 |
9 | Xenon ageing | Pass | ISO 4892-2 |
Specification
Model | Length xWidthx Thickness |
EJGLB72076BK-4500 | 4500mmx19mmx0.76mm |
*Other sizes and packing are available on requested.
Shelf life and Storage
Jinhan guarantees this product for 3 years,as long as it is stored in their original packaging in a dry and ventilated place (between 0℃ and 30℃)and with relative humidity of up to 75%.
