Application
◆ Anti-tracking insulation for cable joints and terminations.
◆ Arc-resistant insulation for electrical connections.
◆ Surface protection for medium-voltage cable accessories.
◆ Insulation and protection of bus bars and electrical connections.
◆ Weather-resistant insulation for outdoor electrical applications.
◆ Insulation and sealing of cable splices and terminations up to 15kV.
Product Features
l Highly tracking resistance;
l Resistance to solvents;
l Withstand -50°C to 250°C;
l Resistance to ozone, UV, and xenon exposure;
Technical Properties
Property | Typical Value | Test Method |
Tensile strength | 6.76Mpa | ASTM D 4325 |
Elongation at break | 480% | ASTM D 4325 |
Heat ageing (250°C 168H) | Pass | ASTM D 4325 |
Ozone ageing | Pass | ASTM D 1373 |
UV ageing | Pass | ASTM D 1373 |
Xenon ageing | Pass | ISO 4892-2 |
Specification
Model | Length xWidthx Thickness |
EJGLB73030GY-1500 | 1500mmx19mmx0.3mm |
EJGLB73050GY-1500 | 1500mmx25mmx0.5mm |
*Other sizes and packing are available on requested.
Shelf life and Storage
Jinhan guarantees this product for 3 years,as long as it is stored in their original packaging in a dry and ventilated place (between 0℃ and 30℃)and with relative humidity of up to 75%.
